LPDA Signal Booster Antenna 698~2700MHz (11dBi) 2G,3G,LTE,WiFi

Operates within B1,B3,B8,B7,B28

Bandwidth 698~2700MHz

Outdoor mast mounted: all brackets included

High gain: 11dBi

2G,3G,4G, LTE bands and WiFi

Voice and Data

5G available in 698~4000MHz, Low PiM

R795,00 Incl. VAT

With many people working from home on a full time basis and kids requiring internet for school and recreation, stable internet is a necessity. Network operators understand this and are in the process of expanding their capacity not only with cellular base stations but also by obtaining more spectrum from ICASA. This will enable LTE to be used to its full potential in South Africa. 5G is fast emerging and will as the network operators establish their network coverage produce staggering data speeds and will unleash new and exciting products. This however will also bring new challenges wrt signal penetration and new design antennas which SD Experts is already geared for.

Safe and Secure Online Shopping or Walk-in

In Cellular & Wireless Since 2007

Walk in & Call-in Support/Testing/Repair

Free Delivery To Major Centre With A Courier Depot

All Products are NCRC and ICASA Type Approved

Installers throughout South Africa

Kit Includes:

  • 1 x LPDA antenna
  • 1 x Complete bracket set
  • N/Type female termination
  • Shipping size 48 x 22 x 8 cm
  • Weight 1Kg

How it works:

Description

The LPDA Antenna 698~2700MHz – 11dBi is an excellent full spectrum outdoor donor antenna. It is terminated with a N Type female. All mast mountable brackets are included.  The LPDA Antenna can be supplied with per-assembled lengths of low-loss cable  for easy installation and cost saving. The LPDA or log-periodic antenna is not a Yagi antenna as incorrectly referred to. A Yagi is a single band antenna where the LPDA is a ultra wide band antenna.
The LPDA Antenna has the advantage of a high gain, 11dBi, with a good F/B Front to Back Ratio.
The LPDA Antenna can be wall or mast mounted and due to its flat shape is aesthetically pleasing and is corrosion and high wind resistant.

Specification:

  • Freq.: 698-2700 MHz
  • Gain:  11 dBi
  • VSWR: ≤1.5
  • HPBWH: 70° 50°
  • Front to Back Ratio >15dB
  • Polarization: Vertical

Application:

  • Outdoors
  • LPWAN, LoRa, LTE-M, NB-IoT, IoT, M2M applications
  • Cellular networks 2G,3G, 4G & 5G
  • Donor Antenna
  • IEEE 802.11b/g WiFi applications
  • Adheres to safety standards in RSA
  • Mast or wall mountable

Additional information

Weight 1 kg
Dimensions 48 × 22 × 8 cm
